to 5 metric tonne capacity
Three phase(220/380/440V) hoists for heavy
industrial use
FEM Mechanism for Lifting Equipment: FEM4m
40% ED
DSA series fulfills maximum safety requirements,
equipped with
dual safety checking devices.
STANDARD
MODELS
- fitted with deluxe components:
● Dual Brake System
- equipped with electro-magnetic brake
● Overload Alert Limiter
- signaling "beep" sounds when
overloaded SWL 125% above
● Double Action Overwining Limiter
- preventing overlifting or overlowering
of chain, as built-in inside
● Push Button Control Switch
- with Emergency Stop Button
● Heavy-duty Motor
- High torgue motor, insulation class "B".
Frequent rating
available with 40 min. and overheat thermal
sensor built-in.
● Load chain
- Case hardended and abrasion resistant,
positioning
perfectly on load sheave in high speed operation
● Preventive Incorrect Phase Limiter
- preventing a possible wrong installation
of power supply
(1Ph/3Ph) * Only available for 60Hz models
OPTION
● Load chain:
- Black colored(Standard), White zinc-galvanized(*Option)
● Chain container:
- Plastic made(Standard A/B), Steel made(*Option)
|
