1 to 5 metric tonne capacity
Three phase(220/380/440V) hoists for heavy
industrial use
Mechanism for Lifting Equipment: FEM4m/1Bm,
40%/25% ED
DSM series conduct ideal performances with
the traversing motor
trolley, together with dual safety checking
devices.
The motorized trolleys have load bars to
suit all flange widths
on conventional rolled beam girders.
● Simple and infinitely variable adjustment
of the flange width
● Universal travel wheels for all common
steel beams
● Lateral steel guide rollers
STANDARD MODELS
- fitted with deluxe components:
● Dual Brake System
- equipped with electro-magnetic brake
● Overload Alert Limiter
- signaling "beep" sounds when
overloaded SWL 125% above
● Double Action Overwining Limiter
- preventing overlifting or overlowering
of chain, as built-in inside
● Push Button Control Switch
- with Emergency Stop Button
● Heavy-duty Motor
- High torgue motor, insulation class "B".
Frequent rating
available with 40 min. and overheat thermal
sensor built-in.
● Load chain
- Case hardended and abrasion resistant,
positioning
perfectly on load sheave in high speed operation
● Preventive Incorrect Phase Limiter
- preventing a possible wrong installation
of power supply
(1Ph/3Ph) * Only available for 60Hz models
OPTION
● Load chain:
- Black colored(Standard), White zinc-galvanized(*Option)
● Chain container:
- Plastic made(Standard A/B), Steel made(*Option)
|
